NEWVAL BV401 CAST IRON 2PC BODY BALL VALVE, JIS10K FLANGED END
SKU:
6" NEWVAL BV401 CAST IRON 2PC BODY BALL VALVE, JIS10K FLANGED END
Brand: Newval
Category: Process & Control › Valves › Ball Valve
Application: Suitable for water, steam, oil, gases and non abrasive media. Specification: Face to Face Dimensions: JIS B2002 10K End Flanged Dime...
Contact us for pricing
This product requires a custom quote
In Stock
Size
Quantity
Max: 10Description
Application:
- Suitable for water, steam, oil, gases and non abrasive media.
Specification:
- Face to Face Dimensions: JIS B2002 10K
- End Flanged Dimensions: JIS B2239
- Working Temperature: Up to 160°C
- Lever Operated as standard
- Optional: Gear Box, Pneumatic or Electric Actuated
- Blow-Out proof Stem / Full Port
- Gland type (BV-13F) / ISO5211 Mounting Pad (WCB/SS)
- PTFE +15%GF or +25%GF for Seat when required.
- Test Pressure: JIS B2003
- Body : 2.1MPa / 21.5 kg/cm² (Hydrostatic)
- Seat : 1.6MPa / 16.5 kg/cm² (By Water), 0.6MPa / 6 kg/cm² (By Air)
