Vitali Chain Block CK
SKU:
CK1 Vitali Chain Block CK 1 tonnes, 20m
Brand: Vitali
Category: Lifting, Lashing › Chain Block
Chain block CK Type meets all pertinent world standards Hardened steel rollers supporting the load sheaves run smoother and last longer than bearings Spur gear efficiency re...
RM1,015.40
In Stock
Capacity
Length
Quantity
Description
- Chain block CK Type meets all pertinent world standards
- Hardened steel rollers supporting the load sheaves run smoother and last longer than bearings
- Spur gear efficiency reduces operator effort, double pawl and double guide rollers enhance performance, safety and reliability
- Load chain is alloy steel grade 80 according to ISO16877
- Deformation indicators – Two strategically placed marks allows for measurement to determine if the throat opening has changed this indicating abuse or overload
- Equipped with with throat top and bottom drop forged hooks that are designed to bend slowly to warn of overloads
- Every chain block is operationally test to 150% of the rated capacity and issued an individual test certificate with unique serial number.
- Safety factory: 4 times of the rated capacity
- Easy remove top hook for 0.5 ton to 3 ton
| Model No | CK 0.5 | CK 1 | CK 1.5 | CK 2 | CK 3 | CK 5 | CK 10 | CK 20 | CK 30 | |
| Capacity (tonnes) | 0.5 | 1 | 1.5 | 2 | 3 | 5 | 10 | 20 | 30 | |
| No. of Fall | 1 | 1 | 1 | 1 | 2 | 2 | 4 | 8 | 12 | |
| Load Chain (mm) | 6 x 18 | 6 x 18 | 8 x 24 | 8 x 24 | 8 x 24 | 10 x 30 | 10 x 30 | 10 x 30 | 10 x 30 | |
| Pull to Rated Load (N) | 267 | 375 | 357 | 471 | 375 | 399 | 392 | 392 | 415 | |
| Proof Load (tonnes) | 0.75 | 1.5 | 2.25 | 3 | 4.5 | 7.5 | 15 | 25 | 37.5 | |
| Hand Chain (mm) | 5 x 25 x 17 | |||||||||
| Dimensions (mm) | a | 125 | 147 | 183 | 183 | 183 | 214.5 | 388 | 635 | 705 |
| b | 123 | 140 | 158 | 158 | 158 | 185 | 185 | 195 | 350 | |
| c | 35 | 45 | 47 | 52 | 62.5 | 78 | – | – | – | |
| h | 280 | 306 | 368 | 444 | 520 | 616 | 700 | 1000 | 1500 | |
| g | 27 | 33 | 33.5 | 37 | 43.5 | 51 | 64 | 82 | 82 | |
Additional Information
Length
122.52036 cm
Width
0 cm
Height
0 cm
Weight
45 kg
Specifications
Specifications
Capacity
0.5 tonnes, 1 tonnes, 1.5 tonnes, 10 tonnes, 2 tonnes, 20 tonnes, 3 tonnes, 5 tonnes
- Chain block CK Type meets all pertinent world standards
- Hardened steel rollers supporting the load sheaves run smoother and last longer than bearings
- Spur gear efficiency reduces operator effort, double pawl and double guide rollers enhance performance, safety and reliability
- Load chain is alloy steel grade 80 according to ISO16877
- Deformation indicators – Two strategically placed marks allows for measurement to determine if the throat opening has changed this indicating abuse or overload
- Equipped with with throat top and bottom drop forged hooks that are designed to bend slowly to warn of overloads
- Every chain block is operationally test to 150% of the rated capacity and issued an individual test certificate with unique serial number.
- Safety factory: 4 times of the rated capacity
- Easy remove top hook for 0.5 ton to 3 ton
| Model No | CK 0.5 | CK 1 | CK 1.5 | CK 2 | CK 3 | CK 5 | CK 10 | CK 20 | CK 30 | |
| Capacity (tonnes) | 0.5 | 1 | 1.5 | 2 | 3 | 5 | 10 | 20 | 30 | |
| No. of Fall | 1 | 1 | 1 | 1 | 2 | 2 | 4 | 8 | 12 | |
| Load Chain (mm) | 6 x 18 | 6 x 18 | 8 x 24 | 8 x 24 | 8 x 24 | 10 x 30 | 10 x 30 | 10 x 30 | 10 x 30 | |
| Pull to Rated Load (N) | 267 | 375 | 357 | 471 | 375 | 399 | 392 | 392 | 415 | |
| Proof Load (tonnes) | 0.75 | 1.5 | 2.25 | 3 | 4.5 | 7.5 | 15 | 25 | 37.5 | |
| Hand Chain (mm) | 5 x 25 x 17 | |||||||||
| Dimensions (mm) | a | 125 | 147 | 183 | 183 | 183 | 214.5 | 388 | 635 | 705 |
| b | 123 | 140 | 158 | 158 | 158 | 185 | 185 | 195 | 350 | |
| c | 35 | 45 | 47 | 52 | 62.5 | 78 | – | – | – | |
| h | 280 | 306 | 368 | 444 | 520 | 616 | 700 | 1000 | 1500 | |
| g | 27 | 33 | 33.5 | 37 | 43.5 | 51 | 64 | 82 | 82 | |
